攤晾機全部采用304拉絲方管和304拉絲板焊接而成，強度高，外觀整齊美觀，不生銹，易保養擦拭；內部風室設計有直通排水口，鏈道風室等可直接用水沖刷。
The paver is welded with 304 square drawing pipe and 304 wire drawing plate, with high strength, neat and beautiful appearance, no rust, easy maintenance and wiping; the internal air chamber is designed with direct drainage outlet and chain duct air chamber, which can be washed with water directly.
整機變頻調速控制，自動加曲速度無級調節，出料口加紅外溫度傳感器，自動控制凉糟溫度，根據溫度控制風機啟停個數及風量大小，達到凉糟降溫目的，并降耗。
The whole machine is controlled by frequency conversion and speed regulation, with stepless adjustment of automatic bending speed. Infrared temperature sensor is added at the discharge port to automatically control the temperature of slag. According to the temperature, the starting and stopping number of fans and the air volume are controlled to achieve the purpose of reducing the temperature of waste grains and energy saving.
主傳動采用國產減速機和一級大模數齒輪傳動，結構緊湊，輸出力矩大，不易損壞；涼糟鏈條運行速度變頻器控制，在0.5-2.6m/m范圍內無級調整，滿足凉糟機工藝要求；凉糟機出口安裝有溫度傳感器，實時測控出糟溫度并控制涼糟鏈條運行速度，保證攤晾效果；
The main drive adopts domestic famous brand reducer and first-class large modulus gear transmission, with compact structure, large output torque and is not easy to be damaged; the running speed of the cooling grain chain is controlled by frequency converter, which can be adjusted steplessly in the range of 0.5-2.6m/m to meet the process requirements of the distiller; a temperature sensor is installed at the outlet of the distiller to measure and control the temperature of the outlet in real time and control the running speed of the chain to ensure the spreading effect;
涼糟篩板用304不銹鋼沖制成型，節距100，寬度1220，篩孔采用長條孔，無飛邊毛刺，透氣性好；篩板底部滾輪支撐，料斗下料時篩板不變形；
The screen plate is made of 304 stainless steel, the pitch is 100, the width is 1220, the sieve hole is long hole, no flash burr, good air permeability; the roller support at the bottom of the sieve plate, the sieve plate does not deform when the hopper is feeding;
采用三臺或四臺強力離心風機冷卻酒糟，風機均可變頻調速和工頻運行，根據出口溫度由電腦自動控制每臺風機的開停變頻運行和工頻運行，配合兩套翻渣輥對酒糟翻動,既減少耗能，又可保證酒糟攤晾效果；每個風機獨立風室經優化設計，內部設計有專門結構，分層送風，保證篩板均勻受風冷卻；
Three or four powerful centrifugal fans are used to cool the distiller's grains. The fans can be variable frequency speed regulation and power frequency operation. According to the outlet temperature, the computer will automatically control the start-up and stop of each fan and power frequency operation, and cooperate with two sets of slag turning rollers to turn the distiller's grains, It can reduce energy consumption and ensure the effect of distiller's grains spreading and airing. After optimization design, each fan's independent air chamber has a special structure, and the air supply is layered to ensure the sieve plate is evenly cooled by wind;
按配套工藝要求設計的加曲機可自動加曲，帶稱重傳感器，自動調節電機頻率控制加曲配比，可精確控制加曲比例；酒糟加曲后經揚片機翻拌后落入料斗（或接糟池），保證加曲后的充分混合；
The koji adding machine designed according to the matching process requirements can automatically add koji, with weighing sensor, automatically adjust the frequency of motor to control the ratio of adding starter, which can accurately control the proportion of adding starter; after adding starter, the distiller's grains will fall into the hopper (or distiller's pool) after being turned over by the tablet lifter to ensure the full mixing after adding starter;
不銹鋼涼茬機 不銹鋼數控涼茬機 酒廠設備
Stainless steel stubble cooling machine stainless steel CNC stubble cooling machine distillery equipment
攤晾機自帶不銹鋼操作平臺，可隨時觀察機器工作情況并可隨時人工介入調整。
The paver is equipped with stainless steel operation platform, which can observe the working condition of the machine at any time and adjust it manually at any time.
攤晾機出口處設計有不銹鋼漿水噴淋管，方便酒糟攤晾后加漿水，將水管裝有流量計加漿水均勻可控。
A stainless steel spray pipe is designed at the outlet of the machine, which is convenient for adding slurry water after the distiller's grains are aired. The water pipe is equipped with a flowmeter and the slurry adding water is uniform and controllable.
機器風室都設計有清理門，方便機器內部殘渣清掃。
The air chamber of the machine is designed with cleaning door, which is convenient for cleaning the residue inside the machine.
